Sync Kubernetes secrets across clusters with External Secrets Operator

Last validated:

Managing secrets across multiple Kubernetes clusters is one of the harder problems in multi-cluster operations. Teams commonly resort to copying secrets between clusters manually, committing encrypted secrets to Git, or running a centralized vault that requires additional infrastructure. Each approach introduces operational burden or security risk.

External Secrets Operator (ESO) solves this by synchronizing secrets from external providers into Kubernetes. Its Kubernetes provider can read secrets directly from a remote cluster's API server, making it possible to treat one cluster as a secret source for others. The challenge is connecting ESO to those remote API servers securely.

This guide combines External Secrets Operator with the Tailscale Kubernetes Operator to sync secrets from a source cluster (the cluster that holds the canonical secrets) to one or more workload clusters over a private network. You'll configure Tailscale egress services to route traffic from ESO to the source cluster's API server, authenticated through Tailscale's Kubernetes impersonation. No secrets are stored in Git, no API servers are exposed to the internet, and adding a new workload cluster requires only a new egress service and a ClusterSecretStore.

External Secrets Operator logo and Tailscale logo side by side, representing the integration between the two tools for cross-cluster secret synchronization.

Prerequisites

Before following this guide, make sure you have:

Install the Tailscale Kubernetes Operator with API server proxy

Install the Tailscale Kubernetes Operator in your source cluster with the API server proxy enabled. This exposes the cluster's API server in your tailnet so that ESO in other clusters can read secrets from it.

helm upgrade --install tailscale-operator tailscale/tailscale-operator \
  --namespace=tailscale \
  --create-namespace \
  --set-string oauth.clientId=<YOUR_OAUTH_CLIENT_ID> \
  --set-string oauth.clientSecret=<YOUR_OAUTH_CLIENT_SECRET> \
  --set operatorConfig.hostname=source-k8s-operator \
  --set apiServerProxyConfig.mode=true \
  --set apiServerProxyConfig.allowImpersonation=true \
  --wait

The key configuration options are:

  • apiServerProxyConfig.mode=true: Enables the Kubernetes API server proxy, exposing the API server in your tailnet.
  • apiServerProxyConfig.allowImpersonation=true: Lets Tailscale impersonate Kubernetes users and groups on behalf of connecting clients. This is how ESO authenticates — the bearer token is not used directly.

The workload clusters also need the Tailscale Kubernetes Operator installed, but they don't require the API server proxy:

helm upgrade --install tailscale-operator tailscale/tailscale-operator \
  --namespace=tailscale \
  --create-namespace \
  --set-string oauth.clientId=<YOUR_OAUTH_CLIENT_ID> \
  --set-string oauth.clientSecret=<YOUR_OAUTH_CLIENT_SECRET> \
  --set operatorConfig.hostname=workload-k8s-operator \
  --wait

Configure access control policies

External Secrets Operator authenticates to the source cluster's API server through Tailscale Kubernetes impersonation. You need to configure access control policies that grant the workload clusters permission to read secrets from the source cluster.

Add the following grants to your tailnet policy file. You can update the tailnet policy file from the Access controls page of the admin console:

This grants policy uses application capabilities to provide fine-grained access to the source cluster's Kubernetes API. The impersonate field controls which Kubernetes groups the workload cluster's operator can act as.

{
  "grants": [
    {
      "src": ["tag:k8s-operator"],
      "dst": ["tag:k8s-operator"],
      "app": {
        "tailscale.com/cap/kubernetes": [
          {
            "impersonate": {
              "groups": ["tailscale:external-secrets"]
            }
          }
        ]
      }
    }
  ]
}

You can use the visual policy editor to manage your tailnet policy file. Refer to the visual editor reference for guidance on using the visual editor.

This policy lets any device tagged k8s-operator to impersonate the tailscale:external-secrets group when accessing another k8s-operator device's Kubernetes API.

The impersonate.groups field is the key connection between Tailscale access control and Kubernetes RBAC. When ESO's request reaches the source cluster's API server proxy, Tailscale identifies the calling device, checks that it has a matching grant, and forwards the request with the Kubernetes impersonation header Impersonate-Group: tailscale:external-secrets. The Kubernetes API server then evaluates the request as if it came from a member of that group. This means you control what ESO can do by creating a Kubernetes ClusterRoleBinding that binds the impersonated group to a ClusterRole.

Use a dedicated impersonation group like tailscale:external-secrets rather than system:masters. This follows the principle of least privilege, granting only the permissions ESO needs rather than full cluster admin access.

Create RBAC for the impersonated group on the source cluster

The grant above causes requests from workload clusters to arrive at the source cluster's API server as the tailscale:external-secrets group. You now need to bind that group to a Kubernetes ClusterRole that grants the permissions ESO requires.

Create a ClusterRole and ClusterRoleBinding on the source cluster:

apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: external-secrets-reader
rules:
  - apiGroups: [""]
    resources: ["secrets"]
    verbs: ["get", "list", "watch"]
  - apiGroups: ["authorization.k8s.io"]
    resources: ["selfsubjectrulesreviews"]
    verbs: ["create"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: external-secrets-reader
subjects:
  - kind: Group
    name: tailscale:external-secrets
    apiGroup: rbac.authorization.k8s.io
roleRef:
  kind: ClusterRole
  name: external-secrets-reader
  apiGroup: rbac.authorization.k8s.io

The ClusterRoleBinding subject group (tailscale:external-secrets) must match the impersonate.groups value in the grant exactly. The selfsubjectrulesreviews permission is required because ESO performs a self-check to verify it has the necessary permissions before attempting to read secrets.

Apply this to the source cluster:

kubectl apply -f rbac.yaml --context source-k8s-operator.<YOUR_TAILNET_NAME>.ts.net

For tighter security, use a namespaced Role and RoleBinding instead of ClusterRole to restrict access to specific namespaces. For example, to restrict ESO to only read secrets from the default namespace:

apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  name: external-secrets-reader
  namespace: default
rules:
  - apiGroups: [""]
    resources: ["secrets"]
    verbs: ["get", "list", "watch"]
  - apiGroups: ["authorization.k8s.io"]
    resources: ["selfsubjectrulesreviews"]
    verbs: ["create"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: external-secrets-reader
  namespace: default
subjects:
  - kind: Group
    name: tailscale:external-secrets
    apiGroup: rbac.authorization.k8s.io
roleRef:
  kind: Role
  name: external-secrets-reader
  apiGroup: rbac.authorization.k8s.io

Create a Tailscale egress service in the workload cluster

In each workload cluster, create a Kubernetes Service that routes traffic to the source cluster's API server through Tailscale. This egress service gives ESO a stable in-cluster hostname to reach the remote API server.

apiVersion: v1
kind: Service
metadata:
  name: source-k8s-operator
  annotations:
    tailscale.com/tailnet-fqdn: source-k8s-operator.<YOUR_TAILNET_NAME>.ts.net
    tailscale.com/proxy-group: <YOUR_PROXY_GROUP>
spec:
  externalName: placeholder
  type: ExternalName
  ports:
  - name: https
    port: 443
    protocol: TCP

Replace <YOUR_TAILNET_NAME> with your tailnet's MagicDNS domain and <YOUR_PROXY_GROUP> with the name of your proxy group. The Tailscale Kubernetes Operator automatically provisions this service and routes traffic to the source cluster through the tailnet.

Apply this to your workload cluster in the namespace where the Tailscale operator manages egress services (typically tailscale):

kubectl apply -f egress-service.yaml -n tailscale

The operator creates a backing ClusterIP service that pods in the workload cluster can use to reach the source cluster's API server. Pods anywhere in the cluster can resolve the MagicDNS hostname source-k8s-operator.<YOUR_TAILNET_NAME>.ts.net to this ClusterIP address.

Set up DNS resolution for MagicDNS

The ClusterSecretStore uses a MagicDNS hostname (for example, source-k8s-operator.<YOUR_TAILNET_NAME>.ts.net) as the server URL. For ESO pods to resolve this hostname to the egress service's ClusterIP, you need to configure DNS resolution for .ts.net domains inside the cluster.

Create a DNSConfig resource in each workload cluster. This deploys a Tailscale nameserver that resolves .ts.net hostnames:

apiVersion: tailscale.com/v1alpha1
kind: DNSConfig
metadata:
  name: ts-dns
spec:
  nameserver:
    image:
      tag: unstable

Apply this to your workload cluster:

kubectl apply -f dns-config.yaml

Get the IP address of the Tailscale nameserver:

kubectl get dnsconfig ts-dns -o jsonpath='{.status.nameserverStatus.ip}'

Make a note of the IP address returned (for example, 100.64.0.4 or 10.100.124.196). Update your CoreDNS configuration to forward .ts.net queries to the Tailscale nameserver:

kubectl edit configmap coredns -n kube-system

Add the following block to the Corefile section, replacing <TAILSCALE_NAMESERVER_IP> with the IP address you noted:

ts.net:53 {
    errors
    cache 30
    forward . <TAILSCALE_NAMESERVER_IP>
}

This step is required. Without it, ESO cannot resolve the .ts.net MagicDNS hostname in the ClusterSecretStore server URL, and the store will fail to connect.

Configure a ClusterSecretStore

Create a ClusterSecretStore in each workload cluster that points to the source cluster through the Tailscale egress service. This tells ESO how to connect to the remote cluster and authenticate.

First, create a placeholder token secret. The Tailscale API server proxy handles authentication through impersonation (configured in the access control policies above), so the bearer token is not used directly. However, ESO's Kubernetes provider requires a token reference in the ClusterSecretStore spec:

apiVersion: v1
kind: Secret
metadata:
  name: tailscale-api-token
  namespace: external-secrets
type: Opaque
stringData:
  token: "unused"

The bearer token value is "unused" because authentication is handled entirely by Tailscale impersonation.

Then create the ClusterSecretStore:

apiVersion: external-secrets.io/v1
kind: ClusterSecretStore
metadata:
  name: kubernetes-source
spec:
  provider:
    kubernetes:
      remoteNamespace: default
      server:
        url: https://source-k8s-operator.<YOUR_TAILNET_NAME>.ts.net
      auth:
        token:
          bearerToken:
            name: tailscale-api-token
            namespace: external-secrets
            key: token

The server.url uses the MagicDNS hostname, which resolves to the egress service's ClusterIP inside the workload cluster. The TLS certificate served by the Tailscale API server proxy is valid for this hostname, so no caBundle is needed. ESO falls back to system certificate authority (CA) roots when no CA is explicitly configured, and Let's Encrypt certificates (used by Tailscale) are included in the system trust store.

When a request arrives at the API server proxy, Tailscale identifies the source device, maps it to the impersonation groups defined in your access control policy, and forwards the request with those credentials. The ESO Kubernetes provider requires a bearerToken field, so a placeholder secret satisfies the schema.

Apply the ClusterSecretStore:

kubectl apply -f cluster-secret-store.yaml

Verify the store is healthy:

kubectl get clustersecretstore kubernetes-source

The STATUS column should show Valid, meaning ESO can successfully connect to the source cluster.

Create an ExternalSecret

With the ClusterSecretStore configured, you can now create ExternalSecret resources that pull specific secrets from the source cluster into the workload cluster. For example, to sync a TLS certificate:

apiVersion: external-secrets.io/v1
kind: ExternalSecret
metadata:
  name: <YOUR_SECRET_NAME>
  namespace: <YOUR_NAMESPACE>
spec:
  refreshInterval: 1h
  secretStoreRef:
    kind: ClusterSecretStore
    name: kubernetes-source
  target:
    name: <YOUR_SECRET_NAME>
    creationPolicy: Owner
  data:
    - secretKey: ca.crt
      remoteRef:
        key: <YOUR_SOURCE_SECRET>
        property: ca.crt
    - secretKey: tls.crt
      remoteRef:
        key: <YOUR_SOURCE_SECRET>
        property: tls.crt
    - secretKey: tls.key
      remoteRef:
        key: <YOUR_SOURCE_SECRET>
        property: tls.key

Apply the ExternalSecret:

kubectl apply -f external-secret.yaml

Verify the secret was synced:

kubectl get externalsecret <YOUR_SECRET_NAME> -n <YOUR_NAMESPACE>

The STATUS column should show SecretSynced. ESO will re-fetch the secret from the source cluster at the refreshInterval you specified, keeping the workload cluster's copy up to date automatically.

Conclusion

You've configured External Secrets Operator to sync secrets between Kubernetes clusters over Tailscale's private network. Secrets are fetched directly from the source cluster's API server through an encrypted mesh connection, with no intermediate storage or internet exposure.

This configuration provides several key benefits:

  • No secrets in Git: Credentials are synced at runtime from the source of truth, not committed to repositories.
  • Automatic rotation: ESO re-fetches secrets on a configurable interval, picking up rotations without manual intervention.
  • Private connectivity: The source cluster's API server is never exposed to the internet. All traffic flows through Tailscale's encrypted network.
  • Fine-grained access: Tailscale impersonation and Kubernetes RBAC work together to grant ESO exactly the permissions it needs and nothing more.
  • Scalable: Adding a new workload cluster requires only a new egress service and ClusterSecretStore. No changes are needed on the source cluster.

For advanced configurations, explore customizing the Tailscale Kubernetes Operator or refer to the External Secrets Operator documentation for additional providers and secret store types.
